RING GROUP
The UCM6100 supports ring group feature with different ring strategies applied to the ring group members.
This section describes the ring group configuration on the UCM6100.
CONFIGURE RING GROUP
Ring group settings can be accessed via Web GUI->PBX->Call Features->Ring Group.
Figure 111: Ring Group
 Click on “Create New Ring Group” to add ring group.
 Click on to edit the ring group. The following table shows the ring group configuration parameters.
 Click on to delete the ring group.
Table 66: Ring Group Parameters
Ring Group Name
Configure ring group name to identify the ring group. Letters, digits, _ and
– are allowed.
Extension
Configure the ring group extension.
Ring Group Members
Select available users from the left side to the ring group member list on
the right side. Click on to arrange the order.
Selected LDAP Numbers
Select available remote users from the left side to the ring group member
list on the right side. Click on to arrange the order. Note:
LDAP Sync must be enabled first.
Ring Strategy
Select the ring strategy. The default setting is “Ring in order”.
 Ring simultaneously.
Ring all the members at the same time when there is incoming call to
the ring group extension. If any of the member answers the call, it will
stop ringing.
 Ring in order.
Ring the members with the order configured in ring group list. If the
first member doesn’t answer the call, it will stop ringing the first
member and start ringing the second member.
