Grandstream Networks UCM6102 User Manual

Firmware Version 1.0.9.26
UCM6100 Series IP PBX User Manual
Page 38 of 305
Table 3: LCD Menu Options
View Events
 Critical Events
 Other Events
Device Info
 Hardware: Hardware version number
 Software: Software version number
 P/N: Part number
 WAN MAC: WAN side MAC address (UCM6102 only)
 LAN MAC: LAN side MAC address
 Uptime: System up time
Network Info
For UCM6104/UCM6108/UCM6116:
 LAN Mode: DHCP, Static IP, or PPPoE
 LAN IP: IP address
 LAN Subnet Mask
For UCM6102:
 WAN Mode: DHCP, Static IP, or PPPoE
 WAN IP: IP address
 WAN Subnet Mask
 LAN IP: IP address
 LAN Subnet Mask
Network Menu
For UCM6104/UCM6108/UCM6116:
 LAN Mode: Select LAN mode as DHCP, Static IP or PPPoE
 Static Route Reset: Click to reset the static route setting
For UCM6102:
 WAN Mode: Select WAN mode as DHCP, Static IP or PPPoE
 Static Route Reset: Click to reset the static route setting
Factory Menu
 Reboot
 Factory Reset
 LCD Test Patterns
Press "OK" to start. Then press "Down" button to test different LCD
patterns. When done, press "OK" button to exit.
 Fan Mode
Select "Auto" or "On".
 LED Test Patterns
