 Click on to create a new static route. The configuration parameters are listed
in the table below.
 Once added, users can select to edit the static route.
 Select to delete the static route.
Table 13: UCM6100 Network Settings->Static Routes
Destination
Configure the destination IP address or the destination IP subnet for the
UCM6100 to reach using the static route.
Example:
IP address - 192.168.66.4
IP subnet - 192.168.66.0
Netmask
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
Gateway
Configure the gateway address so that the UCM6100 can reach the destination
via this gateway. Gateway address is optional.
Example:
192.168.40.5
Interface
Specify the network interface on the UCM6100 to reach the destination using the
static route.
For UCM6102, LAN interface is eth0; WAN interface is eth1.
For UCM6104, LAN1 interface is eth0; WAN interface is eth1.
For UCM6108/UCM6116, only LAN interface is available.
Static routes configuration can be reset from LCD menu->Network Menu.
The following diagram shows a sample application of static route usage on UCM6104.
