Firmware Version 1.0.9.26

UCM6100 Series IP PBX User Manual

Page 40 of 305

Table 5: UCM6108/UCM6116 LED INDICATORS

LED

LED Status

NETWORK

Solid: Connected

OFF: Not Connected

ACT

USB

Phone (FXS)

Line (FXO)

Solid: Connected

Flashing: Data Transferring

OFF: Not Connected

USE THE WEB GUI

ACCESS WEB GUI

The UCM6100 embedded Web server responds to HTTP/HTTPS GET/POST requests. Embedded HTML

pages allow users to configure the device through a Web browser such as Microsoft IE, Mozilla Firefox,

Google Chrome and etc.

Figure 10: UCM6116 Web GUI Login Page
