Firmware Version 1.0.9.26

UCM6100 Series IP PBX User Manual

Page 269 of 305

STATUS AND REPORTING

PBX STATUS

The UCM6100 monitors the status for Trunks, Extensions, Queues, Conference Rooms, Interfaces and

Parking lot. It presents administrators the real time status in different sections under web

GUI->Status->PBX Status.

Figure 152: Status->PBX Status

TRUNKS

Users could see all the configured trunk status in this section.

Figure 153: Trunk Status

Table 93: Trunk Status

Status

Display trunk status.

 Analog trunk status:

Available

Busy

Unavailable

Unknown Error

 SIP Peer trunk status:
