Internal calls
Internal calls are calls from one internal extension to another extension, which are
not sent over a trunk.
External calls
External calls are calls sent from one trunk to another trunk, which are not sent to any
internal extension.
Inbound Trunks
Select certain inbound trunk(s) and the CDR of calls going inbound through the
trunk(s) will be filtered out.
Outbound Trunks
Select certain outbound trunk(s) and the CDR of calls going outbound through the
trunk(s) will be filtered out.
Start Time
Specify the start time to filter the CDR report. Click on the calendar icon on the right
and the calendar will show for users to select the exact date and time.
End Time
Specify the end time to filter the CDR report. Click on the calendar icon on the right
and the calendar will show for users to select the exact date and time.
Caller Number
Enter the caller number to filter the CDR report. CDR with the matching caller
number will be filtered out.
User could specify a particular caller number or enter a pattern. ‘.’ matches zero or
more characters, only appears in the end. ‘X’ matches any digit from 0 to 9,
case-insensitive, repeatable, only appears in the end.
For example:
3XXX: It will filter out CDR that having caller number with leading digit 3 and of 4
digits length.
3.: It will filter out CDR that having caller number with leading digit 3 and of any
length.
Caller Name
Enter the caller name to filter the CDR report. CDR with the matching caller name will
be filtered out.
Callee Number
Enter the callee number to filter the CDR report. CDR with the matching callee
number will be filtered out.
The call report will display as the following figure shows.
Figure 168: Call Report
Users could perform the following operations on the call report.
