UCM6100 Series IP PBX User Manual

Page 221 of 305

BUSY CAMP-ON

Starting from firmware 1.0.8.11, the UCM6100 supports busy camp-on/call completion feature that allows

the PBX to camp on a called party and inform the caller as soon as the called party becomes available

given the previous attempted call has failed.

The configuration and instructions on how to use busy camp-on/call completion feature can be found in the

following guide:

http://www.grandstream.com/products/ucm_series/ucm61xx/documents/ucm6100_busy_camp_on_guide.

pdf
