Hakko Electronics Monitouch V9 Series User Manual

3-6 3. Automationdirect
3.1.3 Direct LOGIC (MODBUS RTU)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
D4-450
PORT1
Set parameters into the special register “R772, 773”, then set “AA5A” (HEX) into the setting complete register “R767”. When
the set value at R767 is changed to “AAAA” (HEX), it is regarded as normal; if it is changed to “AAEA” (HEX), it is regarded as
erroneous.
Parameter setting register
(Underlined setting: default)
Item Setting Remarks
Connection Mode
1:1
/ 1:n / Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C
/ RS-422/485
Baud Rate 4800 / 9600 / 19200
/ 38400 bps
Data Length 8 bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1
Register Setting Setting Example
R772 00E0H
R773
8701H
38400 bps
Odd parity
Stop bit 1
Station number 01
00E0
Communication protocol
20: MODBUS RTU
E0
: Automatic recognition (Modbus, CCM, K-Sequence)
Communication timeout
0: 800 ms
Response delay time
0: 0 ms
8601
Station number
01 to 1F (HEX)
Baud rate
4: 4800 bps
5: 9600 bps
6: 19200 bps
7: 38400 bps
Parity stop bit
0: Without parity, stop bit 1
2: Without parity, stop bit 2
8: Odd parity, stop bit 1
A: Odd parity, stop bit 2
C: Even parity, stop bit 1
E: Even parity, stop bit 2
