Hakko Electronics Monitouch V9 Series - 16.2.28 APR-N (MODBUS RTU)

16-84 16. Fuji Electric
16.2.28APR-N (MODBUS RTU)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
AC Power Regulator
The communication parameter can be set using keys attached to the front of the AC power regulator.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
*1 For communication with V9, select “Network device” for the setting device selection and “MODBUS RTU” for the communication protocol
selection on this regulator.
*2 The communication parameter (data length) is fixed to 8 bits.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
 For word designation, specify the device memory No. (address) in even address.
Example: To make the setting of “output setting” for the function code 1.b01;
Specify “2” in the device memory No. (address).
 For bit designation, it is possible to specify the device memory No. (address) in both even and odd address.
Specify “00H” for the extensional code because the setting range for the bit address is 0 to 7.
Example: To make the setting of “gradient setting selection” for the function code 1.b09;
Specify “1” in the device memory No. (address), “00H” for the extensional code, and “00” or “01” in the bit No..
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600
/ 19200 / 38400 bps
Data Length 8 bits
Stop Bit 1
/ 2 bits
Parity None / Even / Odd
Targe t Por t N o. 1 to 31
Function Code Item Setting Example
6.o02
Setting device selection
*
APd: Setting indicator
nEt: Network device
APr: APR main unit
nEt
7.n01
Communication protocol selection
*
m-S: Master / slave parallel operation
nEt: MODBUS RTU
nEt
7.n02 Station address
A000: 0
A031: 31
(default: A001: 1)
A001
7.n04 Baud rate selection
4800: 4800 bps
9600: 9600 bps
1.920: 19200 bps
3.840: 38400 bps
9600
7.n05 Parity bit + Stop bit selection
P0: Without parity, Stop bit 2 bits
P1: Even parity, Stop bit 1 bits
P2: Odd parity, Stop bit 1 bits
P3: Without parity, Stop bit 1 bits
P2
-
Device Memory TYPE Remarks
--- 02H Byte address
