16.2 Temperature Controller/Servo/Inverter Connection 16-45
16.2.9 FVR-E11S (MODBUS RTU)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Inverter
Be sure to match the communication settings of the inverter to those made on the editor.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600
/ 19200 bps
Data Length 8 bits
Stop Bit 1
/ 2 bits
Parity None
/ Odd / Even
Targe t Por t N o. 1
to 31
Device Memory TYPE Remarks
402H
To Next Page
