16.2 Temperature Controller/Servo/Inverter Connection 16-73
16.2.25PH Series
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Recorder
The communication parameters can be set using keys attached to the front of the recorder.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
* The communication function of the recorder can be selected at the time of purchase. Select a model on which RS-485 transmission mode is
available.
* The communication parameter (data length) is fixed to 8 bits.
Item Setting Remarks
Connection Mode
1 : 1 / 1 : n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1 : n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600 / 19200
bps
Data Length 8 bits
Do not change the default setting because the setting on the
recorder cannot be changed.
Stop Bit 1
/ 2 bits
Parity None / Odd
/ Even
Targe t Por t N o. 1
to 31
Parameter Setting Example Remarks
Station No. 1
to 31 1
Baud rate 4800 / 9600 / 19200
bps 19200 bps
Stop bit 1
/ 2 bits 1
Parity None / Even / Odd
Odd
To Next Page
