16.1.4 MICREX-SX SPH/SPB Series (IEC Mode)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
NP1L-RS1, NP1L-RS2, NP1L-RS3, NP1L-RS4, NP1L-RS5
Mode setting
* Set the port (or CH No.) where the V9 is connected to “loader”.
Communication parameters are fixed to 38400 bps (baud rate), 8 bits (data length), 1 bit (stop bit), and even (parity).
* When the PLC is connected with the V9, the station number setting switch for RS-485 is not used.
Item Setting Remarks
Connection Mode 1:1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C
/ RS-422/485
Baud Rate 38400 bps
For the SPH series:
Do not change the default setting.
Data Length 8 bits
Stop Bit 1 bits
Parity Even
Targe t Por t N o. 0
to 31
MODE Setting
RS1, 2, 4 RS-232C Port RS-485 Port
Remarks
RS3, 5 CH1 CH2
0 General equipment General equipment
1 Loader General equipment
2 General equipment Loader
3Loader Loader
4 General equipment General equipment RS3 and 5 are not used.
5Not used
6 Modem loader 19200 bps General equipment
7 Self-diagnosis mode 1
8 Self-diagnosis mode 2
9 Modem loader 19200 bps Loader
A Modem loader 9600 bps General equipment
B Modem loader 9600 bps Loader
C Modem loader 38400 bps General equipment
D Modem loader 38400 bps Loader
E Modem loader 76800 bps General equipment
F Modem loader 115200 bps Modem loader 115200 bps
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
MODE
