Hakko Electronics Monitouch V9 Series User Manual

1.4 Hardware Settings 1-49
Buzzer
Make settings for the buzzer.
For more information, refer to the V9 Series Reference Manual.
Backlight
Make settings for the backlight.
For more information, refer to the V9 Series Reference Manual.
Local IP Address
*1 For more information on each setting item, see “ Basics of ethernet settings” (page 1-51).
Item Contents
Select IP Address from
Network Table
This is valid when the IP address of the V9 has been registered in the network table.
Select a network table number from 0 to 255 to set the IP address.
* For more information on the network table, refer to “ Network table” (page 1-50).
IP Address
*1
Set the IP address for the V9.
Default Gateway
*1
Set the default gateway.
Subnet Mask
*1
Set the subnet mask.
When this box is not checked, the subnet mask is automatically assigned based on the byte at the extreme
left of the IP address.
Example:
When IP address is “172.16.200.185”, “255.255.0.0” is set.
When IP address is “192.168.1.185”, “255.255.255.0” is set.
Port No.
*1
Set a port number from 1024 to 65535.
Other than 8001.
Send Timeout Specify the timeout time to send the EREAD/EWRITE/SEND/MES command.
Retrials
0 to 255
Set the number of retrials to be performed when a time-out occurs.
Device Protect
Internal Device
Memory Card Device
Check either check box to write-protect the device memory from computers or other stations.
