13-2 13. FANUC
13.1.1 Power Mate
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode 1 : 1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 19200 bps (fixed)
Data Length 8 bits (fixed)
Stop Bit 1 bit (fixed)
Parity Even (fixed)
Device Memory TYPE Remarks
D (data table) 00H
X (input relay) 01H WX as word device
Y (output relay) 02H WY as word device
R (internal relay) 03H WR as word device
K (keep relay) 04H WK as word device
T(timer) 05H
C (counter) 06H
E (extensional relay) 07H WE as word device, available only with 30i/31i/32i-ModelA
