16.1 PLC Connection 16-13
PLC_CTL
The macro command is the same as the one described in “16.1.4 MICREX-SX SPH/SPB Series (IEC Mode)”.
16.1.6 MICREX-SX SPH/SPB CPU (IEC Mode)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
No particular setting is necessary on the PLC.
Communication parameters are fixed to 38400 bps (baud rate), RS-422 (signal level), 8 bits (data length), 1 bit (stop bit), and
even (parity).
Available Device Memory
The available device memory is the same as the one described in “16.1.4 MICREX-SX SPH/SPB Series (IEC Mode)”.
PLC_CTL
The macro command is the same as the one described in “16.1.4 MICREX-SX SPH/SPB Series (IEC Mode)”.
16.1.7 MICREX-SX SPH/SPB CPU (N Mode / F Mode)
Communication Setting
The communication setting is the same as the one described in “16.1.6 MICREX-SX SPH/SPB CPU (IEC Mode)”.
Available Device Memory
The available device memory is the same as the one described in “16.1.5 MICREX-SX SPH/SPB Series (N Mode / F Mode)”.
PLC_CTL
The macro command is the same as the one described in “16.1.4 MICREX-SX SPH/SPB Series (IEC Mode)”.
Item Setting Remarks
Connection Mode 1:1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-422/485
Do not change the setting from default.
Baud Rate 38400 bps
Data Length 8 bits
Stop Bit 1 bit
Parity Even
Targe t Por t N o. 0
to 31
To Next Page
