16.2.7 F-MPC Series / FePSU
Communication Setting
Editor
Communication setting
(Underlined setting: default)
*1 To use port numbers 32 to 99, use the station number table. For the station number table, see “ Station Number Table” (page 16-32).
F-MPC04
Communication setting
The communication parameters can be set using keys attached to the front of the power monitor unit.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
F-MPC04P
Be sure to match the settings to those made under [Communication Setting] of the editor.
Station number setting
Communication setting
The communication parameters can be set using keys attached to the front of the power monitor unit.
(Underlined setting: default)
* The communication parameter (stop bit) is fixed to 1 bit.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600 / 19200
bps
Data Length 7
/ 8 bits
Stop Bit 1 bit
Do not change the default setting because the setting on the
power monitor unit cannot be changed.
Parity None / Odd
/ Even
Targe t Por t N o.
1 to 99
*1
Circuit No. Setting Code Item Setting Example
C
4-0 RS-485 address
Loc: Communication not used
01 to 99
01
4-1 RS-485 baud rate setting
4.8: 4800 bps
9.6: 9600 bps
19.2: 19200 bps
19.2
4-2 RS-485 data length
7: 7 bits
8: 8 bits
7
4-3 RS-485 parity
00: None
01: Even
02: Odd
02
Station Setting Example Remarks
01 to 99 [DEC] (default: 0
)1
Circuit No. Setting Code Item Setting Example
C
L1-
Baud rate
00: 4800 bps
01: 9600 bps
02: 19200 bps
02
L2-
Parity
00: None
01: Even
02: Odd
02
L3-
Data length
00: 7 bits
01: 8 bits
00
ADDRESS SW
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
