Hakko Electronics Monitouch V9 Series User Manual

19-4 19. Hitachi
19.1.2 HIDIC-S10/2, S10mini (Ethernet)
Communication Setting
Editor
Make the following settings on the editor. For more information, see “1.3.2 Ethernet Communication”.
 IP address for the V9 unit
- When specified on the screen program:
[System Setting]  [Hardware Setting]  [Local Port IP Address]
- When specified on the V9 unit:
Local mode  [LAN Setting]
 Port number for the V9 unit (for communication with PLC)
[System Setting]  [Hardware Setting]  [PLC Properties]  [Communication Setting]
 IP address and port number of the PLC
Register on the [PLC Table] in [System Setting]  [Hardware Setting]  [PLC Properties]  [Target Settings].
PLC
LQE020
Module No. setting switch
ET. NET system
Specify the IP address and the subnet mask.
LQE520
Module No. setting switch
S10V ET.NET system
Specify the IP address and the subnet mask.
MODU NO Contents
0 Communication via 10BASE-5
2 Communication via 10BASE-T
MODU NO Contents
0 Communication via 10BASE-5
2 Communication via 10BASE-T
