18.1 PLC Connection 18-5
18.1.2 90 Series (SNP-X)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
Be sure to match the settings to those made under [Communication Setting] of the editor.
90 series (SNP-X)
Calendar
This model is not equipped with the calendar function. Use the built-in clock of the V series.
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
For the device memory address number, specify the value obtained by subtracting “1” from the actual address.
Item Setting Remarks
Connection Mode 1 : 1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 4800 / 9600 / 19200 bps
Data Length 8 bits
Stop Bit 1
/ 2 bits
Parity None / Odd
/ Even
Item Setting Remarks
Baud Rate 19200 bps
Parity Odd
Transmission code
Data Length 8 bits
Stop Bit 1 bit
Function SNP-X
Device Memory TYPE Remarks
R (register) 00H
I (input) 01H
Q (output) 02H
M (internal relay) 03H
G (global relay) 04H
AI (analog input) 05H
AQ (analog output) 06H
T (temporary memory relay) 07H
S (system status) 08H Read only
SA (system status) 09H
SB (system status) 0AH
SC (system status) 0BH
