18-4 18. GE Fanuc
IC693CMM311
(Underlined setting: default)
Calendar
This model is not equipped with the calendar function. Use the built-in clock of the V series.
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
For the device memory address number, specify the value obtained by subtracting “1” from the actual address.
Item Setting Remarks
Configuration Mode
CCM ONLY, CCM/RTU, RTU/CCM,
SNP/CCM, CCM/SNP
Port 1
CCM Enable YES
CCM Mode SLAVE
Interface RS-232
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity NONE / ODD
Retry Count NORMAL / SHORT
Timeout LONG
/ MEDIUM / SHORT / NONE
Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
CCM CPU ID 1 to 31
Port 2
CCM Enable YES
CCM Mode SLAVE
Interface RS-232
/ RS-485
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity NONE / ODD
Retry Count NORMAL / SHORT
Timeout LONG
/ MEDIUM / SHORT / NONE
Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
CCM CPU ID 1 to 31
Device Memory TYPE Remarks
R (register) 00H
I (input) 01H
Q (output) 02H
