18-6 18. GE Fanuc
18.1.3 90 Series (SNP)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
Be sure to match the settings to those made under [Communication Setting] of the editor.
IC693CMM311 / IC697CMM711
(Underlined setting: default)
90-30 Series / 90-70 Series
(Underlined setting: default)
Item Setting Remarks
Connection Mode 1 : 1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C
/ RS-422/485
Baud Rate 4800 / 9600 / 19200
/ 38400 / 57600 / 115K bps
Data Length 8
bits
Stop Bit 1
/ 2 bits
Parity None / Odd
/ Even
Item Setting Remarks
Configuration Mode
SNP ONLY, SNP/CCM, CCM/SNP, SNP/RTU,
RTU/SNP
Port 1
SNP Enable YES
SNP Mode SLAVE
Interface RS485
/ RS232 Only RS232C supported by IC693CMM311
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity ODD
/ EVEN / NONE
Stop Bits 1
/ 2
Timeout LONG
/ MEDIUM / SHORT / NONE
Modem Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
Port 2
SNP Enable YES
SNP Mode SLAVE
Interface RS485
/ RS232
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity ODD
/ EVEN / NONE
Stop Bits 1
/ 2
Timeout LONG
/ MEDIUM / SHORT / NONE
Modem Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
Parameter Setting Remarks
Port Mode SNP Slave
Data Rate 4800 / 9600 / 19200
bps
Parity ODD
/ EVEN / NONE
Stop Bits 1
/ 2
Physical Interface 2-wire / 4-wire
Both valid for RS232
