16.2.2 PXR (MODBUS RTU)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Temperature Controller
The communication parameter can be set using keys attached to the front of the temperature controller.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
*1 The communication function of the temperature controller can be selected at the time of purchase. Select a model on which RS-485
(Modbus) communication is available.
*2 The following communication parameters are fixed; baud rate: 9600 bps, data length: 8 bits, and stop bit: 1 bit.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Do not change the default settings because these settings on the
temperature controller cannot be changed.
Baud Rate 9600 bps
Data Length 8 bits
Stop Bit 1 bit
Parity None / Even / Odd
Target Port No. 1 to 31
Parameter Display Item Setting Example
Third block parameter
STno Station number 1
- 31 1
CoM Parity
0: Odd
1: Even
2: None
0
PCoL Communication protocol
1: Modbus
*1
2: Z-ASCII
1
Device Memory TYPE Remarks
000H
101HRead only
402H
303HRead only
