1.3 Connection Methods 1-9
V-SFT Ver. 6 Settings
Hardware Settings
Selecting a device to be connected
Select the device for connection from [System Setting] [Hardware Setting].
PLC properties
Configure [Communication Setting] on the [PLC Properties] window.
For settings other than the above, see “1.4 Hardware Settings” (page 1-43).
Settings of a Connected Device
Refer to the chapter of the respective manufacturer.
For descriptions of connecting PLCs, refer to the manual for each PLC.
Item Contents
Connection Mode 1 : 1
Signal Level
Configure according to the connected device.
Baud Rate
Data Length
Stop Bit
Parity
Target Po r t N o.
Transmission Mode
To Next Page
