15.1.1 APC Series Controller
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
COM1
Communication setting
Make PLC settings using the application software “APC Pro”. For more information, refer to the PLC manual issued by the
manufacturer.
Parity: none, data length: 8 bits, stop bit: 1 bit (fixed)
Signal level selection
COM2
Station number: 0, parity: none, data length: 8 bits, stop bit: 1 bit, baud rate: 115200 bps (fixed)
Calendar
This model is not equipped with the calendar function. Use the calendar function of the V series.
Item Setting Remarks
Connection Mode
1 : 1
/ 1 : n / Multi-link2 / Multi-link2 (Ethernet) /
1 : n Multi-link2 (Ethernet)
Signal Level RS-232C
/ RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400 / 115K
bps
Data Length 8
bits
Stop Bit 1
bit
Parity None
Targe t Por t N o. 0 to 98
Item Setting Remarks
APC system
APC number setup 0 to 98
APC baud rate setup 115200 / 38400 / 19200 / 9600 / 4800
Item Setting Remarks
Jumper
J1-1
J1-2
J1-3
RS-232C
J1-1: Jumper across pins 2 and 3
J1-2: Jumper across pins 2 and 3
J1-3: Jumper across pins 2 and 3
RS-485
J1-1: Jumper across pins 1 and 2
J1-2: Jumper across pins 1 and 2
J1-3: Jumper across pins 1 and 2
