Hakko Electronics Monitouch V9 Series User Manual

15.1 PLC Connection 15-1
15.1 PLC Connection
Serial Connection
*1 For the ladder transfer function, see the V9 Series Reference Manual.
PLC Selection on the
Editor
CPU Unit/Port Signal Level
Connection
Ladder
Transfer
*1
CN1 MJ1/MJ2
APC Series Controller APB-50
COM1
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
RS-422/485 Wiring diagram 1 - C4 Wiring diagram 1 - M4
COM2 RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
