16-50 16. Fuji Electric
16.2.13FRENIC5000 VG7S (MODBUS RTU)
Communication Setting
Editor
Communication setting
(Underlined setting: default)
*1 When no parity setting is made, set “2 bits” for stop bit.
When a parity setting (even or odd) is made, set “1 bit” for stop bit.
When Connecting to the Built-in RS-485 Port on the Inverter:
Set communication parameters.
Be sure to match the settings to those made under [Communication Setting] of the editor.
(Underlined setting: default)
* The communication parameter (data length) is fixed to 8 bits.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 /
Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400
bps
Data Length 8 bits
Do not change the default setting because the setting on the
inverter cannot be changed.
Stop Bit
1
/ 2 bits
*1
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Function Code Item Setting Example
H30
Link function
*1
3
H31 Station address 1
to 31 1
H34 Baud rate
0: 38400 bps
1: 19200 bps
2: 9600 bps
3: 4800 bps
0
H36 Parity bit
0: None
1: Even
2: Odd
1
H37 Stop bit
For Modbus RTU communication, the stop bit setting is automatically
made according to the parity bit setting.
When no parity setting is made, “2 bits” is set for stop bit.
When a parity setting (even or odd) is made, “1 bit” is set for stop bit.
1
H40
Communication protocol
*2
0: FGI-bus
1: SX (loader) protocol
2: Modbus RTU
2
Writing of
Monitor/function Data
Frequency Setting Operation Command
0
1
2
3
