Hakko Electronics Monitouch V9 Series User Manual

18.1 PLC Connection 18-3
18.1.1 90 Series
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
Be sure to match the settings to those made under [Communication Setting] of the editor.
PCM
(Underlined setting: default)
Calendar
This model is not equipped with the calendar function. Use the built-in clock of the V series.
Item Setting Remarks
Connection Mode
1:1
/ 1:n / Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C
/ RS-422/485
Baud Rate 4800 / 9600 / 19200
bps
Data Length 8 bits
Stop Bit 1 bit
Parity None / Odd
Target Port No. 1 to 31
Item Setting Remarks
Configuration Mode CCM ONLY, BAS/CCM, PROG/CCM, CCM/PROG
Port 1
CCM Enable YES
CCM Mode SLAVE
Interface RS-232
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity NONE / ODD
Retry Count NORMAL / SHORT
Timeout LONG
/ MEDIUM / SHORT / NONE
Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
CPU ID 1 to 31
Port 2
CCM Enable YES
CCM Mode SLAVE
Interface RS-232
/ RS-485 Only RS-485 is available with IC693PCM300.
Date Rate 4800 / 9600 / 19200
bps
Flow Control NONE
Parity NONE / ODD
Retry Count NORMAL / SHORT
Timeout LONG
/ MEDIUM / SHORT / NONE
Turnaround Delay NONE
/ 10 ms / 100 ms / 500 ms
CPU ID 1 to 31
