16-72 16. Fuji Electric
Indirect Device Memory Designation
* In the expansion code, set which word, higher or lower, is to be read when a double-word address is specified
(expansion bit designation).
PLC_CTL
Return data: Data stored from the servo amplifier to the V9
15 8 7 0
n + 0 Model Device Memory type
n + 1 Address No.
n + 2
Expansion code
*
Bit designation
n + 3 00 Station number
15 8
0000000
Expansion bit designation
0: 0 to 15 bits
1: 16 to 31 bits
Contents F0 F1 (= $u n) F2
System status readout
1 - 8
(PLC1 - 8)
n Station number
2
n + 1 Command: 0
n + 2 System 1
n + 3 System 2
n + 4 Model
n + 5 Occupied by maker, Zno
n + 6 - n + 10 Occupied by maker (max. 10 bytes)
