16-44 16. Fuji Electric
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
Device Memory TYPE Remarks
S (command data) 00H
M (monitor data) 01H Double-word
F (basic function) 02H
E (terminal function) 03H
C (control function) 04H
P (motor 1) 05H
H (high level function) 06H
A (motor 2) 07H
o (optional function) 08H
Contents F0 F1 (= $u n) F2
Reset command
1 - 8
(PLC1 - 8)
nStation number
2
n + 1 Command: 0
To Next Page
