16.2 Temperature Controller/Servo/Inverter Connection 16-83
Return data: Data stored from the panel meter to the V9
Linearization data setting
1 - 8
(PLC1 - 8)
n Station number
6
36
n + 1 Command: 58
n + 2
Read start number
1 to 16
n + 3
The number of read data
1 to 16
n + 4 Linearization data input value (start number + 0)
n + 5 Linearization data output value (start number + 0)
n + 6 Linearization data input value (start number + 1)
n + 7 Linearization data output value (start number + 1)
n + 8 Linearization data input value (start number + 2)
n + 9 Linearization data output value (start number + 2)
n + 10 Linearization data input value (start number + 3)
n + 11 Linearization data output value (start number + 3)
n + 12 Linearization data input value (start number + 4)
n + 13 Linearization data output value (start number + 4)
n + 14 Linearization data input value (start number + 5)
n + 15 Linearization data output value (start number + 5)
n + 16 Linearization data input value (start number + 6)
n + 17 Linearization data output value (start number + 6)
n + 18 Linearization data input value (start number + 7)
n + 19 Linearization data output value (start number + 7)
n + 20 Linearization data input value (start number + 8)
n + 21 Linearization data output value (start number + 8)
n + 22 Linearization data input value (start number + 9)
n + 23 Linearization data output value (start number + 9)
n + 24 Linearization data input value (start number + 10)
n + 25 Linearization data output value (start number + 10)
n + 26 Linearization data input value (start number + 11)
n + 27 Linearization data output value (start number + 11)
n + 28 Linearization data input value (start number + 12)
n + 29 Linearization data output value (start number + 12)
n + 30 Linearization data input value (start number + 13)
n + 31 Linearization data output value (start number + 13)
n + 32 Linearization data input value (start number + 14)
n + 33 Linearization data output value (start number + 14)
n + 34 Linearization data input value (start number + 15)
n + 35 Linearization data output value (start number + 15)
Contents F0 F1 (=$u n) F2
-
