4-6 4. Azbil
4.2 Temperature Controller/Servo/Inverter Connection
Serial Connection
Digital Indicating Controller
*1 Enter addresses manually by referring to the instruction manual for the controller.
Module-type Controller
Program Controller
PLC Selection
on the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
SDC10 SDC10xxxxx05xx Terminal on the back RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4 SDC10.Lst
SDC20
SDC20xxxx02xx
SDC20xxxx04xx
SDC20xxxx09xx
Terminal on the back RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
SDC20.Lst
SDC20xxxx03xx
SDC20xxxx05xx
SDC20xxxx10xx
Terminal on the back RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
SDC21
SDC21xxxx03xx
SDC21xxxx06xx
SDC21xxxx08xx
Terminal on the back RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
SDC21xxxx04xx
SDC21xxxx07xx
SDC21xxxx09xx
Terminal on the back RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
SDC30/31
SDC30xxxx040xx
SDC30xxxx041xx
Terminal on the back RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4 SDC30.Lst
SDC31xxxx045xx
SDC31xxxx446xx
SDC31xxxx546xx
SDC35/36
SDC35xxxxxx2xx
SDC35xxxxxx4xx
SDC36xxxxxx2xx
SDC36xxxxxx4xx
Terminal on the back RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4
SDC36.Lst
SDC15Txxxx03xx
SDC15Txxxx06xx
SDC25Txxxxx2xx
SDC26Txxxxx2xx
None
*1
SDC40A
SDC40Axxxxxxx2xx
Terminal on the ba ck
RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
SDC40A.Lst
SDC40Axxxxxxx3xx RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
SDC40G SDC40Gxxxxx095xx
Additional terminal on the
back
RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4 SDC40G.Lst
PLC Selection
on the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
DMC10
DMC10S
DMC10D
CPL communication
terminal
RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4 DMC10.Lst
DMC50 (COM)
DMC50ME20X
DMC50MR20X
RS-485 port 1 RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
DMC50.Lst
Display communication
port
RS-485
Wiring diagram 3 - C4 Wiring diagram 3 - M4
DMC50CH40X
DMC50CH20X
DMC50CS40X
DMC50CS20X
Display communication
port
RS-485
AHC2001 AHC2001
CPU RS-232C
Wiring diagram 2 - C2 Wiring diagram 2 - M2
AHC2001.Lst
SCU
RS-232C
RS-485 Wiring diagram 4 - C4 Wiring diagram 4 - M4
AHC2001+DC
P31/32
AHC2001 SCU RS-485 Wiring diagram 4 - C4 Wiring diagram 4 - M4
AHC_DCP.Lst
DCP31Axx0ASxx2xx
DCP32AxxxASxx2xx
Additional terminal on the
back
RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
IBS Terminal block
PLC Selection
on the Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
DCP31/32
DCP31Axx0ASxx2xx
DCP32AxxxASxx2xx
Additional terminal on
the back
RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4 DCP32.Lst
