4-8 4. Azbil
4.2.1 SDC10
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Controller
Make the following settings.
When the [PARA] key is held down for three seconds or longer in the run mode, the parameter mode is selected. When the
[PARA] key is held down for three seconds or longer again, the setup mode is selected.
(Underlined setting: default)
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
* The number of times EEPROM can be reprogrammed is limited (approx. 100,000 times). Accordingly, we recommend that
you write such a parameter as to be reprogrammed frequently into RAM, where the number of reprogramming times is
not limited. However, when the parameter has been written into RAM, and the power is turned off and back on again,
data in EEPROM is transferred.
For more information, refer to the instruction manual for the controller issued by the manufacturer.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-422/485
Baud Rate 4800 / 9600 bps
Data Length 8
bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Item Indication Setting Remarks
Communication
address
C22 1 to 31 Communication is disabled when “0” is set.
Communication
condition
C23
0: 9600 bps, 8 bits, even parity, 1 stop bit
1: 9600 bps, 8 bits, without parity, 2 stop bit
2: 4800 bps, 8 bits, even parity, 1 stop bit
3: 4800 bps, 8 bits, without parity, 2 stop bit
Device Memory TYPE Remarks
--- 00H
Without “*”: RAM
With “*”: RAM + EEPROM
To Next Page
