4.2 Temperature Controller/Servo/Inverter Connection 4-11
4.2.5 SDC35/36
Communication Setting
Editor
Communication setting
(Underlined setting: default)
Controller
CPL communication setting
(Underlined setting: default)
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
* The number of times EEPROM can be reprogrammed is limited (approx. 100,000 times). Accordingly, we recommend that
you write such a parameter as to be reprogrammed frequently into RAM, where the number of reprogramming times is
not limited. However, when the parameter has been written into RAM, and the power is turned off and back on again,
data in EEPROM is transferred.
For more information, refer to the instruction manual for the controller issued by the manufacturer.
Item Setting Remarks
Connection Mode
1:1 / 1:n
/ Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400 bps
Data Length 7 / 8
bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Item (Bank) Indication Setting Remarks
Communication type
(Setup bank)
C64 0: CPL
See “20. MODBUS”.
Device address
(Setup bank)
C65 1 to 127 Communication is disabled when “0” is set.
Baud rate
(Setup bank)
C66
0: 4800 bps
1: 9600 bps
2: 19200 bps
3: 38400 bps
Data type: data length
(Setup bank)
C67
0: 7 bits
1: 8 bits
Data type: parity
(Setup bank)
C68
0: Even
1: Odd
2: None
Data type: stop bit
(Setup bank)
C69
0: 1 bit
1: 2 bits
Device Memory TYPE Remarks
--- 00H
Without “*”: RAM
With “*”: RAM + EEPROM
To Next Page
