5-2 5. Baumuller
5.1.1 BMx-x-PLC
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
No particular setting is necessary on the PLC.
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
* The assigned device memory is expressed as shown on the
right when editing the screen.
Item Setting Remarks
Connection Mode 1 : 1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400 bps
Data Length 8
bits
Stop Bit 1
bit
Parity Even
Device Memory TYPE Remarks
DB (Data Block) 00H
