6-4 6. BECKHOFF
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
Return data: Data stored from temperature controller to V series
*1 Port setting values
*2 Setting values for “Index Group” and “Index Offset”
Contents F0 F1 (= $u n) F2
Access Inputs
1 - 8
(PLC1 - 8)
nStation number
7
n + 1 Command: 0001H
n+2
Port
*1
n+3
Index Group
*2
n+4
n+5
Index Offset
*2
n+6
n+7
Data
Access Outputs
1 - 8
(PLC1 - 8)
nStation number
8
n + 1 Command: 0002H
n+2
Port
*1
n+3
Index Group
*2
n+4
n+5
Index Offset
*2
n+6
n+7 Data
Port Name
100 Logger (only NT - Log)
110 Eventlogger
300 IO
301 Additional Task 1
302 Additional Task 2
801 PLC Run-time System 1
811 PLC Run-time System 2
821 PLC Run-time System 3
831 PLC Run-time System 4
900 Camshaft Controller
10000 System Service
14000 Scope
Access
Index Group Index Offset Description
Input Output
00004020H 0 - 65535 READ_M / WRITE_M
00004025H 0 PLCADS_IGR_RMSIZE
0000F003H 0 GET_SYMHANDLE_BYNAME
0000F005H 0 - 4294967295
READ_SYMVAL_BYHANDLE
WRITE_SYMVAL_BYHANDLE
0000F006H 0 RELEASE_SYMHANDLE
0000F020H 0 - 4294967295 READ_I / WRITE_I
0000F025H 0 ADSIGRP_IOIMAGE_RISIZE
0000F030H 0 - 4294967295 READ_Q / WRITE_Q
0000F035H 0 ADSIGRP_IOIMAGE_ROSIZE
