8.1 PLC Connection 8-1
8.1 PLC Connection
Serial Connection
*1 For the ladder transfer function, see the V9 Series Reference Manual.
PLC Selection
on the Editor
CPU Unit/Port Signal Level
Connection
Ladder
Transfer
*1
CN1 MJ1/MJ2
BP series
CM2-BPxxMDxx-R
CM2-BPxxMDxx-T
CM2-BPxxMDxx-S
CM2-BPxxMDxx-U
LOADER port RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
CM2-BPxxMDxx-R Comm port RS-232C Wiring diagram 3 - C2 Wiring diagram 3 - M2
CM2-BPxxMDxx-T
CH1 RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
CH2 RS-422/485 Wiring diagram 3 - C4 Wiring diagram 1 - M4
CM2-BPxxMDxx-S Comm port RS-422/485 Wiring diagram 1 - C4 Wiring diagram 2 - M4
CM2-BPxxMDxx-U
CH1 RS-422 Wiring diagram 2 - C4
CH2 RS-422/485 Wiring diagram 3 - C4 Wiring diagram 1 - M4
CP series
CM1-CPxx LOADER port RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
CM1-CP4C Comm port RS-232C Wiring diagram 4 - C2 Wiring diagram 4 - M2
CM1-CP4D Comm port RS-422/485 Wiring diagram 4 - C4 Wiring diagram 3 - M4
CM1-CPxx
CM1-SC01A CH1 RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
CM1-SC01B
CH1 RS-422 Wiring diagram 5 - C4
CH2 RS-422/485 Wiring diagram 5 - C4 Wiring diagram 4 - M4
CM1-SC02A
CH1 RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
CH2 RS-422/485 Wiring diagram 5 - C4 Wiring diagram 4 - M4
