9-2 9. DELTA
9.1.1 DVP Series
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
(Underlined setting: default)
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode
1:1
/ 1:n / Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 9600 / 19200 / 38400 / 57600 / 115200 bps
Data Length 7
/ 8 bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Item Setting Remarks
Baud rate 9600
For more information, refer to the PLC
manual issued by the manufacturer.
Station number 1
Data length 7
Stop bit 1
Parity Even
Device Memory TYPE Remarks
D(Data register) 00H
X (Input relay) 01H Read only
Y(Output relay) 02H
M (Auxiliary relay) 03H
S04H
T(Timer) 05H
C (Counter) 06H
32C (High-speed counter) 07H Double-word
To Next Page
