11-2 11. EATON Cutler-Hammer
11.1.1 ELC
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
Make the PLC setting using device memory “D” (data register). For more information, refer to the PLC manual issued by the
manufacturer.
Available Device Memory
The available setting range of device memory varies depending on the PLC model. Be sure to set within the range available for
the PLC to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Item Setting Remarks
Connection Mode
1:1
/ 1:n / Multi-link2 / Multi-link2 (Ethernet) /
1:n Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400 / 57600 / 115200 bps
Data Length 7
/ 8 bits
Stop Bit 1
/ 2 bits
Parity None / Odd / Even
Targe t Por t N o. 1 to 31
Device Memory TYPE Remarks
D(data register) 00H
X (input) 01H Read only
Y(output) 02H
M (auxiliary relay) 03H
S(step point) 04H
T(timer) 05H
C (counter) 06H
32C (high-speed counter) 07H Double-word
