14.1 PLC Connection 14-1
14.1 PLC Connection
Serial Connection
*1 For the ladder transfer function, see the V9 Series Reference Manual.
PLC Selection
on the Editor
CPU Unit/Port Signal Level
Connection
Ladder
Transfer
*1
CN1 MJ1/MJ2
FACON
FB series
FBE-20MC
FBE-28MC
FBE-40MC
CPU unit
Programming port
Port1 RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
Port2 RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4
FB-DTBR
Port1
(D-sub 15)
RS-232C Wiring diagram 1 - C2 Wiring diagram 1 - M2
Port1
(D-sub 9)
RS-232C Wiring diagram 2 - C2 Wiring diagram 2 - M2
Port2
(terminal block)
RS-485 Wiring diagram 2 - C4 Wiring diagram 2 - M4
