16-48 16. Fuji Electric
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
When “S” (command data) or “M” (monitor data) is used:
For the device memory address number, specify the value obtained by subtracting “1” from the actual address.
PLC_CTL
Macro command “PLC_CTL F0 F1 F2”
Device Memory TYPE Remarks
S (command data) 00H
M (monitor data) 01H Double-word, read only
F (basic function) 02H
E (terminal function) 03H
C (control function) 04H
P (motor 1) 05H
H (high level function) 06H
A (motor 2) 07H
o (optional function) 08H
U (user function) 0AH
Contents F0 F1 (= $u n) F2
Reset command
1 - 8
(PLC1 - 8)
nStation number
2
n + 1 Command: 0
To Next Page
