16.2 Temperature Controller/Servo/Inverter Connection 16-57
*1 Select “Modbus RTU” for the communication protocol on the inverter when connecting with the V9.
*2 When “0” is specified for y98 (bus function) as well as y99 (support link function), the frequency and operation command can be set on
the V9.
When making the frequency and operation command settings on the V9 connected to the connector for the touch panel, specify “3” for
function code H30. When making those settings on the V9 connected to the optional communication board, specify “8” for function code
H30.
*3 The communication parameter (data length) is fixed to 8 bits.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
y99 Support link function 0
H30
Link function
*2
3
Function
Code
Item Setting Example
Frequency Operation Command
0 Function code H30, y98 Function code H30, y98
1 Commanded from RS-485 Function code H30, y98
2 Function code H30, y98 Commanded from RS-485
3 Commanded from RS-485 Commanded from RS-485
Frequency Operation Command
0 Inverter Inverter
1 RS-485 communication Inverter
2 Inverter RS-485 communication
3 RS-485 communication RS-485 communication
4 RS-485 communication (optional) Inverter
5 RS-485 communication (optional) RS-485 communication
6 Inverter RS-485 communication (optional)
7 RS-485 communication RS-485 communication (optional)
8 RS-485 communication (optional) RS-485 communication (optional)
Device Memory TYPE Remarks
4 02H
