PLC_CTL
Return data: Data stored from servo amplifier to V9 series
*1 Select station No. 0 for broadcast commands.
Contents F0 F1 (= $u n) F2
Reading of
positioning data
1 - 8
(PLC1 - 8)
n Station number
4
n+1 Command: 03 (HEX)
n+2 Reading address
n+3 Number of positioning data to read: m (1 to 9)
n+4
Positioning
data
m = 1
Positioning status & M code
n+5 Stop timer
n+6 to n+7 Stop position
n+8 to n+9 Rotation speed
n+10 to n+11 Acceleration time
n+12 to n+13 Deceleration time
n+14 to
n+(3+10m)
Positioning data (m = 2)
Writing of
positioning data
1 - 8
(PLC1 - 8)
n
Station number
*1
4+10m
n+1 Command: 10 (HEX)
n+2 Writing address
n+3 Number of positioning data to write: m (1 to 9)
n+4
Positioning
data
m = 1
Positioning status & M code
n+5 Stop timer
n+6 to n+7 Stop position
n+8 to n+9 Rotation speed
n+10 to n+11 Acceleration time
n+12 to n+13 Deceleration time
n+14 to
n+(3+10m)
Positioning data (m = 2)
Bit 15 - 8 76543210
Command
method
Step mode
Not used
M code
Valid/invalid
M code output timing
Not used
M code
Bit 15 - 8 76543210
Command
method
Step mode
Not used
M code
Valid/invalid
M code output timing
Not used
M code
