16-92 16. Fuji Electric
Calendar
This model is equipped with a calendar function; however, the calendar data cannot be written from the V series. Thus, time
correction must be performed on the controller side.
Available Device Memory
The available setting range of device memory varies depending on the model. Be sure to set within the range available for the
model to be used. Use [TYPE] when assigning indirect device memory for macro programs.
Indirect Device Memory Designation
* In the expansion code, set which word, higher or lower, is to be read when a double-word address is specified.
Device Memory TYPE Remarks
R (data register) 00H
D (data register) 01H
X (input relay) 02H WX as word device
Y (output relay) 03H WY as word device
M (internal relay) 04H WM as word device
S (step relay) 05H WS as word device
T (timer/contact) 06H WT as word device
C (counter/contact) 07H WC as word device
TR (timer/current value) 08H
CR (counter/current value) 09H
32CR (32-bit counter/current value) 0AH Double-word
15 8 7 0
n + 0 Model Device type
n + 1 Address No.
n + 2
Expansion code
*
Bit designation
n + 3 00 Station number
