19.1 PLC Connection 19-7
19.1.4 HIDIC-S10V
Communication Setting
Editor
Communication setting
(Underlined setting: default)
PLC
All PLC parameters are fixed to the following settings:
Baud rate: 19200 bps, data length: 8 bits, stop bit: 1 bit, parity: odd
However, when the optional RS-232C/RS-422 module is used, the channel and the protocol must be set using the channel
No./protocol setting switch.
Channel No./Protocol Setting Switch
A maximum of two RS-232C/RS-422 modules (four channels) can be attached to one CPU. When using multiple channels, set
a unique channel number (#1 to #4) for each.
LQE560 / LQE565
Item Setting Remarks
Connection Mode 1:1
/ Multi-link2 / Multi-link2 (Ethernet)
Signal Level RS-232C / RS-422/485
Baud Rate 4800 / 9600 / 19200 / 38400 / 57600 / 115K bps
Data Length 8 bits
Stop Bit 1 bit
Parity Odd
MODU NO Communication Mode Channel No.
8
H-7338 protocol
#0
9 #1
A #2
E #3
To Next Page
