20.2 Temperature Controller/Servo/Inverter Connection
Inverter
PLC Selection on the
Editor
Model Port Signal Level
Connection
Lst File
CN1 MJ1/MJ2
SJ300 series
SJ300
SJH300
TM2 RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4 H_SJ300.Lst
SJ700 series
SJ700
SJ700-2
TM2 RS-485 Wiring diagram 1 - C4 Wiring diagram 1 - M4 H_SJ700.Lst
