20.2 Temperature Controller/Servo/Inverter Connection 20-21
Intelligent terminal
status setting
1 - 8
(PLC1 - 8)
n Station number
6
n + 1 Command: 2
n + 2
Data (HH)
n + 3
Data (HL)
n + 4
Data (LH)
n + 5
Data (LL)
Contents F0 F1 (= $u n) F2
Bit 0: “STAT” Pulse train input enabled
1514131211109876543210
Bit 0: “SF1” Multistep speed (bit operation)
Bit 1: “SF2” Multistep speed (bit operation)
Bit 2: “SF3” Multistep speed (bit operation)
Bit 3: “SF4” Multistep speed (bit operation)
Bit 4: “SF5” Multistep speed (bit operation)
Bit 5: “SF6” Multistep speed (bit operation)
Bit 6: “SF7” Multistep speed (bit operation)
Bit 7: “OLR” Overload limitation selection
Bit 8: “TL” Torque limitation valid/invalid
Bit 9: “TRQ1” Torque limit selection 1
Bit 10: “TRQ2” Torque limit selection 2
Bit 11 “PPI” P/PI selection
Bit 12: “BOK” Brake check
Bit 13: “ORT” Orientation
Bit 14: “LAC” LAD cancel
Bit 15: “PCLR” Positioning deviation clear
1514131211109876543210
Bit 0: “AT” Analog input selection
Bit 1: “SET3” 3rd control
Bit 2: “RS” Reset
Bit 3: --
Bit 4: “STA” 3-wire start
Bit 5: “STP” 3-wire retain
Bit 6: “F/R” 3-wire normal/reverse turn
Bit 7: “PID” PID selection (valid/invalid)
Bit 8: “PIDC” PID integral reset
Bit 9: --
Bit 10: “CAS” Control gain selection
Bit 11: “UP” Remote control acceleration
Bit 12: “DWN” Remote control deceleration
Bit 13: “UDC” Remote control data clear
Bit 14: --
Bit 15: “OPE” Forced operation
1514131211109876543210
Bit 0: “FW” Normal turn command
Bit 1: “RV” Reverse turn command
Bit 2: “CF1” Multistep speed 1 (binary operation)
Bit 3: “CF2” Multistep speed 2 (binary operation)
Bit 4: “CF3” Multistep speed 3 (binary operation)
Bit 5: “CF4” Multistep speed 4 (binary operation)
Bit 6: “JG” Jogging (inching operation)
Bit 7: “DB” External DC braking
Bit 8: “SET” 2nd control
Bit 9: “2CH” 2-step acceleration/deceleration
Bit 10: --
Bit 11: “FRS” Free-run stop
Bit 12: “EXP” External trip
Bit 13: “USP” Unattended start protection function
Bit 14: “CS” Commercial switching
Bit 15: “SFT” Soft lock (control terminal block)
1514131211109876543210
