20.2 Temperature Controller/Servo/Inverter Connection 20-27
20.2.3 Wiring Diagrams
When Connected at CN1:
RS-485
Wiring diagram 1 - C4
When Connected at MJ1/MJ2:
RS-485
Wiring diagram 1 - M4
* Use shielded twist-pair
cables.
RP
Name
SN
SP
1
No.
Dsub 9 (Male)
2
3
4
-RD
-SD
+SD
5SG
+RD
FG
CN1
Name
SN
5
9
1
6
* Use shielded twist-pair cables.
* RP-SN short-circuited at the termination
* Use shielded twist-pair cables.
SN
SP
Name
RP
SN
RJ - 45
Name
No.
1
2
5
12345678
+RD/+SD
-RD/-SD
SG
FG
MJ1/2
* RP-SN short-circuited at the termination
