2-22 2. ALLEN BRADLEY
Address denotations
The assigned device memory is expressed as shown below when editing the screen.
 Address other than input/output
- For word access For bit access
The file number will not be displayed for the input, output or status device memory.
 Input/output address
- For word access For bit access
Indirect Device Memory Designation
 Specify the file number or slot number and the element number for the address number.
Example: When specifying N007:123
Specify “7123” (DEC) for the address number.
Example: When specifying N120:123
Specify “120123” (DEC) for the address number.
120123 (DEC) is equivalent to 1D53B (HEX). Specify “D53B (HEX)” for the lower address number and “0001”
for the upper address number.
 When specifying an address for the timer (control), counter (control) or control device memory in bit designation, specify
the bit number in decimal notation as shown below:
- T: Timer (control)
DN = 13, TT = 14, EN = 15
- C: Counter (control)
UA = 10, UN = 11, OV = 12, DN = 13, CD = 14, CU = 15
-R: Control
FD = 08, IN = 09, UL = 10, ER = 11, EM = 12, DN = 13, EU = 14, EN = 15
Element number
File number
Device type
Nxxx: yyy
Bit number
Element number
File number
Device type
Nxxx: yyy/zz
I: xxx. yyy
I: xxx. yyy/zz
Element number
Slot No.
Device type
Bit number
Element number
Slot No.
Device type
MSB LSB
n + 0 Model Device type
n + 1 Address No.
n + 2 00 Bit designation
n + 3 00 Station number
15 8 7 0
MSB LSB
n + 0 Model Device type
n + 1 Lower address No.
n + 2 Higher address No.
n + 3 00 Bit designation
n + 4 00 Station number
 For the file or slot numbers 0 to 65:
 For the file or slot numbers 66 to 255:
15 8 7 0
