Chapter 4 Device Configuring Using the Front Panel Routing and Descrambling
© 2012 Harmonic Inc. 47 ProView 7000 v.2.6, Rev. E
You can use any multiplex for routing.
Each multiplex menu comprises the following sub-menus:
■ Activation
❑ Enable – Enable the multiplex and automatically create a TS cross connect to the
corresponding multiplex out. If the corresponding multiplex out already has a program
on it, it is removed. If the corresponding multiplex out already has a TS on it, the
multiplex in cross connects with the first available multiplex out.
❑ Disable – Only removes the TS cross connect from the multiplex out, the multiplex
remains enabled.
■ Redundancy Mode
❑ Off
❑ Manual
❑ Manual Revert
❑ Automatic
❑ Automatic Revert
■ Active Input – Use this menu to display or change the active input port.
■ Primary Input – When using multiplex input port redundancy use this menu to select one of
the following physical input ports for the primary input, Redundancy Mode must be set to
any mode but Off:
❑ SAT 1
❑ SAT 2
8
❑ SAT 3
❑ SAT 4
❑ ASI 1
❑ ASI 2
❑ ASI 3
9
❑ ASI 4
9
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
■ Backup Input– When using multiplex input port redundancy use this menu to select one of
the following physical input ports for the backup input, Redundancy Mode must be set to
any mode but Off:
❑ SAT 1
❑ SAT 2
8
❑ SAT 3
❑ SAT 4
8. The number of RF satellite inputs depends on your hardware configuration.
9. ProView 7000™
