Chapter 4 Device Configuring Using the Front Panel Routing and Descrambling
© 2012 Harmonic Inc. 48 ProView 7000 v.2.6, Rev. E
❑ ASI 1
❑ ASI 2
❑ ASI 3
9
❑ ASI 4
9
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
■ Input Selection – This menu only displays when Redundancy Mode is set to Off. Use this
menu to select one of the following physical input ports:
❑ SAT 1
❑ SAT 2
10
❑ SAT 3
❑ SAT 4
❑ ASI 1
❑ ASI 2
❑ ASI 3
11
❑ ASI 4
9
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
❑ None
■ Output Selection – This menu only displays when Redundancy Mode is set to Off. Use this
menu to individually enable or disable the following physical outputs:
❑ ASI 1
❑ ASI 2
❑ ASI 3
❑ ASI 4
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
■ Descrambling – Select a program then select one of the following CAM options:
❑ BISS
❑ CAM 1
10. The number of RF satellite inputs depends on your hardware configuration.
11. ProView 7000™
