MediaStore5100 and 5000 series troubleshooting and maintenance
muted, it continues to sound with short intermittent bleeps to indicate that a problem still exists. It will be
silenced when all problems are cleared.
The Alarm Silence Button can be used to test the LEDs on the Operators Panel. When the Alarm
Silence Button is pressed and held, all LEDs will be illuminated if there are no faults present.
Table 9-6: Audible alarm states
Alarm state Action Action with Alarm Silence
button pressed
S0 Normal mode: silent Beep twice
S1 Fault mode: 1 sec on/1 sec off Transition to S2
S2 Remind mode: intermittent beep None
S3 Muted mode: silent None
S4 Critical fault mode: continuous
alarm
None: mute not active
Note the following about Audible Alarm States:
• When an alarm is in state S1, and you do not mute the alarm within two minutes, the alarm will
automatically transition to state S2.
• Alarm states S1 to S4 return to state S0 when you clear the fault.
• Alarm state S4 can be entered from any other alarm state
Audible alarm conditions
Certain MediaStore alerts result in an audible alarm.
Status Severity Alarm
PCM alert—loss of DC power from a single
PCM
Fault—no loss of redundancy S1
PCM alert—loss of DC power from a single
PCM
Fault—loss of redundancy S1
PCM fan fail Fault—loss of redundancy S1
SBB module detected PCM fault Fault S1
MediaStore configuration error Fault—critical S1
Low temperature alert Warning S1
High temperature alert Warning S1
Over temperature alarm Fault—critical S4
I
2
C bus failure Fault—loss of redundancy S1
Ops panel communication error (I
2
C) Fault—critical S1
RAID error Fault—critical S1
SBB interface module fault Fault—critical S1
209 Spectrum System 8.4 Installation Guide
